EURO-85DCSU

TECHNICAL SPECIFICATION
No. of Colors 2
Doctoring Cup Dia [mm] 90
Print Speed [Max. /Hrs] 1000
Cliché/Plate Size [mm] 100 X 210
Print Image Size [mm] 85
Product Height [mm]300
Power Consumption [W] 50
Control System Micro Processor
Control Voltage 12/24 VDC
Drive Electro Pneumatic
Operating Pressure 5-7 bar
Air Consumption [Lit/min.] 110
Power Supply 230 VAC/50Hz.
Dimensions (Approx)Length - 670 mm, Width - 820 mm, Height - 1270 mm
Weight (Approx)116 Kgs


SAMPLES
