No. of Colors | 1 |
Doctoring Cup Dia [mm] | 60 |
Cliche/Plate Size [mm] | 70 x 140 |
Print Speed [Max./Hrs] | 2000 |
Print Image Size [ mm] | 55 |
Product Height [mm] | 400 |
Power Consumption [W] | 120 |
Control System | Electrical |
Control Voltage | 09/12 VDC |
Drive | Electro Mechanical |
Operating Pressure | Not Required |
Air Consumption [Lit/min.] | No |
Power Supply | 230 VAC/50Hz |
Dimensions (Approx) | Length - 580 mm, Width - 310 mm, Height - 1180 mm |
Weight (Approx) | 80 Kgs |
