| No. of Colors | 1 |
| Doctoring Cup Dia [mm] | 90 |
| Cliche/Plate Size [mm] | 100 x 210 |
| Print Speed [Max./Hrs] | 2000 |
| Print Image Size [ mm] | 85 |
| Product Height [mm] | 400 |
| Power Consumption [W] | 250 |
| Control System | Electrical |
| Control Voltage | 09/12 VDC |
| Drive | Electro Mechanical |
| Operating Pressure | Not Required |
| Air Consumption [Lit/min.] | No |
| Power Supply | 230 VAC/50Hz |
| Dimensions (Approx) | Length - 660 mm, Width - 320 mm, Height - 1240 mm |
| Weight (Approx) | 120 Kgs |
