| No. of Colors | 2 |
| Doctoring Cup Dia [mm] | 130 |
| Print Speed [Max. /Hrs] | 600 |
| Cliché/Plate Size [mm] | 150 X 300 |
| Print Image Size [ mm] | 120 |
| Product Height [mm] | 200 |
| Power Consumption [W] | 50 |
| Control System | Micro Processor |
| Control Voltage | 12/24 VDC |
| Drive | Electro Pneumatic |
| Operating Pressure | 5-7 bar |
| Air Consumption [Lit/min.] | 160 |
| Power Supply | 230 VAC/50Hz. |
| Dimensions (Approx) | Length - 900 mm, Width - 950 mm, Height - 1420 mm |
| Weight (Approx) | 215 Kgs |
