Model No. | EURO-85PC |
No. of Colors | 1 |
Doctoring Cup Dia [mm] | 90 |
Print Speed [Max. /Hrs] | 750 |
Cliché/Plate Size [mm] | 100 X 210 |
Print Image Size [ mm] | 85 |
Product Height [mm] | 200 |
Power Consumption [W] | 250 |
Control System | PLC + HMI |
Control Voltage | 12/24 VAC |
Drive | Electro Pneumatic |
Operating Pressure | 7-9 bar |
Air Consumption [Lit/min.] | 300 Approx. |
Power Supply | 230 VAC/50Hz. |
Dimensions (Approx) | Length - 920 mm, Width - 700 mm, Height - 1350 mm |
Weight (Approx) | 225 Kgs |
