| Model No. : | Ecoo-OP 210 |
| No. of Colors : | 1 |
| Doctoring Cup Dia [mm] : | 90 |
| Print Speed [Max./Hrs] : | 2400 |
| Cliche/Plate Size [mm] : | 100 X 210 |
| Print Image Size [mm] : | 75 X 35 or Ø 80 |
| Product Height [mm] : | |
| Power Consumption [W] : | 50 |
| Control System : | Micro Processor |
| Control Voltage : | 12/24 VAC |
| Drive : | Electro Pneumatic |
| Operating Pressure[Bar] : | 5-7 |
| Air Consumption [Lit/min.] : | 100 |
| Power Supply : | 230 VAC/50Hz. |
| Dimensions (Approx) [mm] : | Length - 600 mm |
| Width - 310 mm | |
| Height - 600 mm | |
| Weight (Approx) [Kgs]: | 43 Kgs |
