| Model No. | Euro-85-250pc |
| No. of Colors | 1 |
| Doctoring Cup Dia [mm] | 90 |
| Print Speed [Max./Hrs] | 1000 |
| Cliche/Plate Size [mm] | 100 X 250 |
| Print Image Size [ømm] | 85 |
| Product Height [mm] | 200 |
| Power Consumption [W] | 50 |
| Control System | PLC + HMI |
| Control Voltage | 12/24 VDC |
| Drive | Electro Mechanical |
| Operating Pressure | 6-8 |
| Air Consumption [Lit/min.] | 120 |
| Power Supply | 230 VAC/50Hz. |
| Dimensions (Approx) | Length - 1020 mm |
| Width - 750 mm | |
| Height - 1410 mm | |
| Weight (Approx) | 158 Kgs |
