| Model No. | Euro-85-500hpdx |
| No. of Colors | 1 |
| Doctoring Cup Dia [mm] | 90 |
| Print Speed [Max./Hrs] | 500 |
| Cliche/Plate Size [mm] | 100 X 500 |
| Print Image Size [ømm] | 70 X 300 |
| Product Height [mm] | 400 |
| Power Consumption [W] | 50 |
| Control System | Micro Processor |
| Control Voltage | 12/24 VDC |
| Drive | Electro Pneumatic |
| Operating Pressure | 6-8 |
| Air Consumption [Lit/min.] | 120 |
| Power Supply | 230 VAC/50Hz. |
| Dimensions (Approx) | Length - 810 mm |
| Width - 645 mm | |
| Height - 1300 mm | |
| Weight (Approx) | 131 Kgs |
